DS-3WRE3N

User Manual: DS-3WRE3N

Quick Start Guide: DS-3WRE3N

General

• Product Dimension (W × H × D): 111mm×56mm×47.7mm
• Package Dimension (W × H × D): 148mm×98mm×72mm
• Net Weight: 0.221 kg
• Packing List
  • WiFi Extender× 1
  • Quick Start Guide × 1
  • Regulatory Compliance and Safety Information × 1
• Packing Method: Single pack
• Working Temperature: 0 ℃ to 40 ℃ (32 ℉ to 104 ℉)
• Working Humidity: 10% to 90% RH non-condensing
• Storage Temperature: -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
• Storage Humidity: 10% to 90% RH non-condensing
• Max. Power Consumption: ≤ 3.8 W
• Gross Weight: 0.192 kg

Wireless Parameter

• Data Rate
  • ≤ 300 Mbps
  • 2.4 GHz: 300 Mbps
• Wireless Standard: IEEE802.11b,IEEE 802.11g, IEEE 802.11n @2.4GHz
• Working Frequency Band: 2.4 GHz
• Transmitting Power: <20dBm
• Wireless Performance: 2*2 MIMO supported
• Receiving Sensitivity
  • 2.4 GHz
  • 11b-1M:-96dBm
  • 11g-54M:-77dBm
  • 11n-20M-MCS7:-75dBm
  • 11n-40M-MCS7:-73dBm
• Antenna: 2*3dBi external antennas

Hardware Parameter

• LED Indicator: 1 * Signal/Power/WPS LED
• Reset
  • 1 * WPS Button
  • 1 * Reset Button
• Power Supply Method: 100-240V ~50/60HZ 0.3A

Software Function

• Application function: Repeater Mode
• Security Mode
  • Default encryption mode: Mix WPA-PSK/WPA2-PSK
  • WPA algorithm: TKIP
• Security Mechanism: Hide SSID
• Management Method: Web
• Upgrade: Web
• System Log: Firmware upgrade, Restore factory settings, Login password, and Reboot
